Briquet Making Machinery

Briquet Making Machinery parameter

Briquet making machinery can be used to press coal powder, iron powder, coking coal, aluminum powder, iron filings, iron oxide, carbon powder, carbon powder, slag, gypsum, tailings, sludge, kaolin, activated carbon, coke powder and other powders and powders.

The main engine of the briquet making machinery is powered by an electromagnetic speed-regulating motor, which is transmitted to the drive shaft through a pulley, a cylindrical gear reducer, and a rod-pin coupling. when there is too much material between the two rollers or into the metal block, the piston rod of the hydraulic cylinder is overloaded under pressure, the hydraulic pump stops, the accumulator buffers the pressure change, the overflow valve opens and returns oil, the piston rod will shift, increasing The gap between the large rollers allows hard objects to pass through the rollers, and the system pressure returns to normal, which protects the rollers from damage.

The drive shaft the briquet making machinery and the driven shaft run synchronously through open gears. A hydraulic device is installed behind the passive bearing housing. The hydraulic protection device is driven by the hydraulic pump to drive the high pressure oil into the hydraulic cylinder to make the piston produce axial displacement.

The front end of the piston rod rests on the bearing housing to meet production pressure requirements.when too much material is fed between the two pressure rollers or a metal block enters, the piston rod of the hydraulic cylinder is overloaded by pressure, the hydraulic pump will stop, the accumulator will buffer the pressure change, the relief valve will open to return oil, and the piston rod will shift.increase the gap between the rollers so that hard objects pass through the rollers, and the system pressure returns to normal, which can protect the rollers from damage.
