1315 Impact Crusher Parameter：
Model | Specification | Feed Opening Size(mm) | Feeding Size (mm) | Capacity (t/h) | Motor Power(kw) | Overall Dimension(mm) |
PF-1007 | Φ1000 × 700 | 400 x 730 | ≤250 | 15-60 | 45 | 2319 x 1654 x 2558 |
PF-1010 | Φ1000 × 1050 | 400x1080 | ≤300 | 50-90 | 55 | 2319 x 2001 x 2558 |
PF-1210 | Φ1250 × 1050 | 450x1060 | ≤300 | 80-150 | 90 | 2585 x 2053 x 2809 |
PFV-1214 | Φ1250 × 1400 | 450x1440 | ≤300 | 100-200 | 132 | 2582 x 2403 x 2809 |
PFV-1315 | Φ1320 × 1500 | 550x1530 | ≤350 | 130-280 | 160 | 2930 x 2761 x 3053 |
PFV-1320 | Φ1320 × 2000 | 610x1900 | ≤500 | 180-400 | 220 | 3224 x 3175 x 2706 |
PFV-1520 | Φ1500 x 2000 | 830x2040 | ≤700 | 300-550 | 315-400 | 3959 x 3564 x 3330 |
PFV-1820 | Φ1800 x 2000 | 1260x2040 | ≤800 | 600-800 | 630-710 | 4400 x 3866 x 4009 |
Introduction
The models of the 1315 Impact Crushers are: 1010, 1210, 1214, 1315, 1320, 1820, etc. The 1315 type impact crusher is the choice of many customers. The reason why it gets its name is because it is equipped with a rotor specification of Φ1320 ×1500mm, the larger the rotor, the stronger its production capacity. The 1315 counterattack breaker has a production capacity of 100-280t/h.
Application fields
1315 impact crusher is used for crushing machinery in metallurgy, construction, waste concrete, chemical industry, hydro power and other industries. The mouth enters the crushing chamber, is hit by the high-speed rotating hammer, and then strikes back on the impact plate for re-crushing. There are usually three counter boards.
After repeated crushing, the grain shape is more uniform. It is a medium-sized crusher, widely used in stone production. The discharge port is 860mm x 1520mm and can accommodate materials with a side length of less than 500mm. Its output per unit time can follow 160-250 tons.
FAQ
1. What factors affect the output of 1315 impact crusher?
1.Raw material size
The size of the material will affect the output of the crushing equipment during operation. If we put in a large amount of materials, the force performance of the impact crusher will also increase, and the crushing time will be prolonged, thus affecting its output. Therefore, if we crush materials with larger particle sizes, remind us to add a jaw crusher to counterattack. Coarse crushing before the crusher. After the big stone is broken into small ore, the impact crusher will solve it. Relatively simple, the speed will increase, and the output will be firm.
2. Material properties
The viscosity, water content and Mohs hardness of the material are also the main factors affecting the water breaking capacity of the counterattack. For example, if we want to crush hooligans with high water content or high viscosity, the difficulty of crushing will increase, and the output will naturally be unqualified. For some materials with low Mohs hardness and low moisture content, the impact crusher is easy to crush, so the output will naturally increase.
3. The operation of the 1315 Impact Crusher by the workers
If the staff does not grasp the performance and working rules of the impact crusher when using it, it will affect the output and may cause mechanical failure. Therefore, remind everyone to check with the manufacturer before operating the impact crusher. The precautions and correct operation methods in the process of mechanical operation can not only stabilize production, but also ensure our personal safety.
Our service
Pre-sale service:
According to customer needs, we will provide you with free product consulting services, suggest suitable machinery and equipment for you, support customization of the products you need, and select solutions, and provide relevant technical documents in a timely manner.
In-sale service:
The technicians will guide the design, installation, commissioning and delivery of the product on site, and the service is warm and thoughtful, helping to solve difficult problems;
After-sale service:
After debugging, the whole machine leaves the factory to ensure the normal operation of the equipment. All mechanical products are guaranteed for one year, and the wearing parts of accessories are not covered by the warranty.
Introduction of our company
The company is located in Gongyi City, Henan Province, on the edge of the Yellow River, and has mature R&D capabilities. Among them, the engineering stone crushing production line and the construction sand production line are at the industry level.
The business and service organizations are all over the country, and the equipment is exported to Africa, Southeast Asia and other countries. Over the years, with the unique management level and manufacturing technology, rich manufacturing experience and customer-first service spirit, we have produced qualified products and won the trust of users with good comprehensive benefits.
Q: Do your products have certifications?
Q: How is the machine packaged when shipped?
Q: How long is the delivery time?
Q: How about the payment items?
Q: Which country have you exported to?
Q: How is your production capacity?
Q: Can we visit your factory?
Q: How to connect with you?
Why choose us?
- We offer professional and reliable service to all of our customers worldwide.
- While improving the supply and marketing trading platform, we are building a complete bulk commodity logistics system, focusing on the stable and long-term development of the capital market, and building an economy with a full industrial chain of production, supply and marketing.
- Our Impact Crusher products meet international quality standards and are suitable for a variety of applications.
- Our 1315 Impact Crusher has stable demand on the market and the quality is absolutely superior, and its price is quite reasonable.
- Our Impact Crusher products are designed to provide maximum efficiency and reduce downtime.
- Quality assurance, credibility, and enthusiastic service are the tenet of our company.
- We offer customized solutions to meet the unique needs of our customers.
- The advantages of our company have created a solid foundation for the sound development and expansion.
- Our factory is committed to sustainability and environmentally responsible manufacturing practices.
- According to the different application requirements of customers, we provide accurate and advanced various products and solutions.
